Cement bucket elevator

  • Model : NE
  • Bucket Width: 250/300/400/600/700/800mm
  • Bucket Running Speed: 0.5m/s
  • Traction Component: High strength alloy steel plate chain
  • Capacity: 15-800m³/h
  • Max. Lifting height: 40m
  • NE bucket elevator
  • NE bucket elevator
  • NE bucket elevator
  • NE bucket elevator manufacturer
  • NE bucket elevator manufacturer
Introduction
NE type bucket elevator’s traction configuration is plate chain , which is used for vertically transporting powder , granular and block material , and also high grinding material , such as coal powder , slag , limestone , cement raw material , cement clinker , cement , coal , dry clay etc , material temperature is less than 250℃. Max. lifting height can be 40m .It is special for cement,so we also call it cement bucket elevator.

Working Principle and Application

Hopper scoops up materials from the stone bucket below, then is lifted to the top with the conveyor belt or chain, and next it is downward rolled over bypass the wheel on the top and the materials are dumped into the accept slot now by bucket chain or hoist conveyor, and the whole process is over. The driving band of bucket elevator with driver is commonly made of rubber, and it is installed below or above the drive roller and the divert roller. The chain-drive bucket elevator is generally equipped with two parallel transmission chains, above or below which is a drive sprocket and a divert sprocket. Continuous chain or belt bucket elevator for cement is generally equipped with chassis to prevent the dust flying into the bucket elevator.

Advantages and Features

1. Cement bucket elevator machine adopts plate chain, gravity discharge material
2.High strength plate chain of the superior alloy steel is wear-resisting and steady
3. Adopt several kinds of driving groups to drive, there are maintained frame and guardrail on driven platform
4. There are rails and backstops to prevent chain swinging while running
5. The anti-return rubber plate is installed at the discharge outlet
6. Bottom part has the self-tension device
7. Low driving power, inflow feeding, induction unloading, high-volume hopper intensive arrangement
8. Wide lifting range, few requirements of material type and property
9. Good running reliability
10.Long life span

Selection Conditions
♦Material to be processed: _____ ♦Material is corrosive or not: ____ (Ps. Yes or No)
♦Handling capacity (Ps. It means the total ♦Working environment is indoor or outdoor:________
material capacity feeding from the inlet): _____t/h ♦Material is liquid or not:___________(Ps. Yes or No)
♦Bulk Density: _____t/m3 ♦Working environment temperature: _______
♦Lifting height of the elevator (distance  between ♦Upstream equipment (Ps. It means what kind of
 inlet and outlet):__________m equipment is used to feed the material): _____
♦Max. granule size of the feeding material: ____mm ♦Downstream equipment (Ps. It means what kind of
♦Percentage of Max. granule in material:_________% equipment is used to discharge the material): _____
♦Material temperature: _____; ♦Working power supply: _____V ______HZ
♦water content:____%
